Fast, efficient and built for commercial, public & fleet charging. A compact powerhouse engineered for high uptime and reliable performance.
The EVlink Pro DC 60 kW fast charger delivers reliable and efficient charging for commercial sites, public locations, and fleet operations.
Its compact footprint, smart connectivity, and dual-connector design make it the ideal choice for locations needing dependable fast charging without large power requirements.
Built for durability, 24/7 operation, and seamless user experience — it’s a perfect entry-level DC fast charger for Pakistan’s growing EV landscape.
Output power to support commercial & public applications.
Secure user authentication for controlled charging.
Smart load control and energy management for lower operating costs.
Clear, intuitive interface for drivers and operators.
Simultaneous charging for two vehicles. 2x CCS2 or CCS + CHAdeMO
Built-in MCB, RCD, SPD & Emergency Stop for maximum safety.
Shopping malls, supermarkets, real-estate projects & workplaces requiring reliable fast charging.
Urban charging points, parking plazas & public mobility hubs.
Ideal for intercity travel, service areas & rest zones.
Light commercial fleets, ride-hailing operators & delivery vehicles.
Bring convenient, 60 kW fast charging to your site today.
| EV Link Pro DC | 60 kW |
|---|---|
| General | |
| Input Current | 193…214 A |
| Nominal output power | SAE CCS Combo 2: 120 kW at 1.5…300 A150...1000 V DC |
| Output type and range | 2 charging cable of 3.6 m |
| Number of outputs | 2 |
| Connector type | SAE CCS Combo 2 |
| Display type | LCD touch screen : 10 inch |
| Efficiency | 94.5 % |
| Ambient air temperature for operation | -30…50 °C (with derating above 50 °C) |
| Dimensions | |
| Height | 2202 mm |
| Width | 1050 mm |
| Depth | 982 mm |
| Net weight | 470 kg (without power module) 530 kg (with power module) |
| Connectivity | |
| Communication network type | 4G WLAN TCP/IP Wi-Fi |
| Access control system | Badge RFID conforming to ISO/IEC 14443 A and B Badge NFC |
| Communication port protocol | OCPP 1.6 |
| Ethernet service | Web browser |
| Standards & Protections | |
| Protection type | Short-circuit protection on output Overload protection Ground fault protection Residual current breaker with overcurrent protection (RCBO) Temperature rise protection |
| Electromagnetic compatibility | Emission standard for industrial environments: |
| IP degree of protection | IP55 |
| IK degree of protection | IK10 Screen: IK08 |
| Emergency Stop Button | Yes |
| Standards | IEC 61851-1:ed. 3 IEC 61851-23:ed. 1 IEC 62196-1 IEC 62196-3 EN/IEC 61000-6-2:2005 EN/IEC 61000-6-4:class A ISO 15118 DIN 70121 |
| Warranty | |
| Years | 2 Years (Extendable up to 5 years) |
| Others | |
| Language | English |
Most EVs can charge from 20% to 80% in 45–60 minutes depending on battery size and vehicle capability.
Yes. Its compact footprint and dual-connector support make it ideal for public charging points, parking areas, and commercial sites.
Absolutely. With OCPP 1.6J, you can monitor sessions, manage costs, update firmware, and track performance remotely.
